helpers::matrix Class Reference

#include <helpers.h>

Collaboration diagram for helpers::matrix:

Public Member Functions
	matrix ()
	matrix (int n_, int m_)
	matrix (const matrix &orig)
	matrix (matrix &&orig)
virtual	~matrix ()
matrix &	operator= (const matrix &orig)
matrix &	operator= (double val)
int	getn () const
int	getm () const
double	operator() (int x, int y) const
double &	operator() (int x, int y)
double &	operator[] (int x)
double	operator[] (int x) const
double *	getpointer () const
matrix &	prod (matrix const &A, matrix const &B)
std::unique_ptr< double[]>	svd ()
std::unique_ptr< double[]>	sym_eig ()
void	Print () const
double	trace () const
void	SaveToFile (std::string filename) const
void	ReadFromFile (std::string filename) const

Private Attributes
std::unique_ptr< double[]>	mat
	n by m array of double More...
int	n
	number of rows More...
int	m
	number of columns More...

Detailed Description

Helper class, wrapper around a double array. Has methods to get the number of rows and columns. A simple matrix class.

Definition at line 31 of file helpers.h.

Constructor & Destructor Documentation

matrix::matrix

(

)

Empty matrix constructor. Don't use it unless you know what you're doing

Definition at line 43 of file helpers.cpp.

matrix::matrix	(	int	n_,
		int	m_
	)

Parameters

n_	number of rows
m_	number of columns

Definition at line 53 of file helpers.cpp.

matrix::matrix

(

const matrix &

orig

)

Parameters

orig	matrix to copy

Definition at line 64 of file helpers.cpp.

Here is the call graph for this function:

matrix::matrix

(

matrix &&

orig

)

move constructor

Parameters

orig	matrix to copy (descrutive)

Definition at line 76 of file helpers.cpp.

virtual helpers::matrix::~matrix ( )

inlinevirtual

Definition at line 42 of file helpers.h.

Member Function Documentation

int matrix::getm

(

)

const

Returns

number of columns

Definition at line 115 of file helpers.cpp.

int matrix::getn

(

)

const

Returns

number of rows

Definition at line 107 of file helpers.cpp.

double * matrix::getpointer

(

)

const

Definition at line 144 of file helpers.cpp.

Here is the caller graph for this function:

double matrix::operator()	(	int	x,
		int	y
	)		const

Definition at line 120 of file helpers.cpp.

double & matrix::operator()	(	int	x,
		int	y
	)

Definition at line 126 of file helpers.cpp.

matrix & matrix::operator=

(

const matrix &

orig

)

Definition at line 83 of file helpers.cpp.

Here is the call graph for this function:

matrix & matrix::operator=

(

double

val

)

Set all matrix elements equal to a value

Parameters

val	the value to use

Definition at line 96 of file helpers.cpp.

double & matrix::operator[]

(

int

x

)

Definition at line 132 of file helpers.cpp.

double matrix::operator[]

(

int

x

)

const

Definition at line 138 of file helpers.cpp.

void matrix::Print

(

)

const

Definition at line 228 of file helpers.cpp.

matrix & matrix::prod	(	matrix const &	A,
		matrix const &	B
	)

Matrix-Matrix product of A and B. Store result in this

Parameters

A	first matrix
B	second matrix

Definition at line 154 of file helpers.cpp.

Here is the call graph for this function:

void matrix::ReadFromFile

(

std::string

filename

)

const

Definition at line 291 of file helpers.cpp.

void matrix::SaveToFile

(

std::string

filename

)

const

Definition at line 246 of file helpers.cpp.

std::unique_ptr< double[]> matrix::svd

(

)

Do a SVD on this matrix and store left singular values in this. Changes the size of the matrix!

Returns

list of singular values

Definition at line 173 of file helpers.cpp.

Here is the call graph for this function:

std::unique_ptr< double[]> matrix::sym_eig

(

)

calculate eigenvalues of symmetric matrix

Returns

array with the eigenvalues

Definition at line 206 of file helpers.cpp.

Here is the call graph for this function:

double matrix::trace

(

)

const

Definition at line 235 of file helpers.cpp.

Member Data Documentation

int helpers::matrix::m

private

number of columns

Definition at line 82 of file helpers.h.

std::unique_ptr<double []> helpers::matrix::mat

private

n by m array of double

Definition at line 78 of file helpers.h.

int helpers::matrix::n

private

number of rows

Definition at line 80 of file helpers.h.

---

The documentation for this class was generated from the following files:

• include/helpers.h
• helpers.cpp
