#include <PHM.h>

Inheritance diagram for doci2DM::PHM:

Collaboration diagram for doci2DM::PHM:

Public Member Functions
	PHM (int, int)

	PHM (const PHM &)=default

	PHM (PHM &&)=default

virtual	~PHM ()=default

PHM &	operator= (const PHM &)=default

PHM &	operator= (PHM &&)=default

double	operator() (int a, int b, int c, int d) const

const Matrix &	getBlock (int a, int b) const

Matrix &	getBlock (int a, int b)

int	gN () const

int	gL () const

void	G (const TPM &)

Matrix	Gimg (const TPM &) const

Matrix	Gbuild () const

void	sep_pm (BlockMatrix &, BlockMatrix &)

void	sqrt (int)

void	invert ()

void	L_map (const BlockMatrix &, const BlockMatrix &)

void	WriteToFile (hid_t &group_id) const

void	ReadFromFile (hid_t &group_id)

void	WriteFullToFile (hid_t &group_id) const

void	setDim (int, int, int)

BlockStructure &	operator+= (const BlockStructure< BlockType > &)

BlockStructure &	operator-= (const BlockStructure< BlockType > &)

BlockStructure &	daxpy (double alpha, const BlockStructure< BlockType > &)

BlockStructure &	operator*= (double)

BlockStructure &	operator/= (double)

BlockType &	operator[] (int block)

const BlockType &	operator[] (int block) const

double &	operator() (int block, int i, int j)

double	operator() (int block, int i, int j) const

double &	operator() (int block, int index)

double	operator() (int block, int index) const

int	gnr () const

int	gdim (int) const

int	gdeg (int) const

double	trace () const

double	ddot (const BlockStructure< BlockType > &) const

void	dscal (double alpha)

double	min () const

double	max () const

void	fill_Random ()

void	fill_Random (int)

virtual void	L_map (const BlockStructure< BlockType > &, const BlockStructure< BlockType > &)

virtual BlockStructure< BlockType > &	mprod (const BlockStructure< BlockType > &, const BlockStructure< BlockType > &)

void	symmetrize ()

void	sort ()

template<>
void	sort ()

virtual void	sep_pm (BlockStructure< BlockType > &, BlockStructure< BlockType > &)

Private Member Functions
void	constr_lists (int L)

Private Attributes
int	L

int	N

Static Private Attributes
static std::unique_ptr< helpers::tmatrix< int > >	s2ph = nullptr
	table translating single particles indices to two particle indices More...

static std::unique_ptr< helpers::tmatrix< int > >	ph2s = nullptr
	table translating two particles indices to single particle indices More...

static std::unique_ptr< helpers::tmatrix< int > >	s2b = nullptr
	table translating single particles indices to the correct 2x2 block More...

static std::unique_ptr< helpers::tmatrix< int > >	b2s = nullptr
	table translating the block index to the single particle indices More...

Friends
std::ostream &	operator<< (std::ostream &output, PHM &phm)

Detailed Description

Definition at line 38 of file PHM.h.

Constructor & Destructor Documentation

PHM::PHM	(	int	L,
		int	N
	)

Parameters

L	the number of levels
N	the number of particles

Definition at line 40 of file PHM.cpp.

Here is the call graph for this function:

doci2DM::PHM::PHM ( const PHM & )

default

doci2DM::PHM::PHM ( PHM && )

default

virtual doci2DM::PHM::~PHM ( )

virtualdefault

Member Function Documentation

void PHM::constr_lists ( int L )

private

Definition at line 56 of file PHM.cpp.

Here is the caller graph for this function:

template<class BlockType >

BlockStructure< BlockType > & BlockStructure::daxpy	(	double	alpha,
		const BlockStructure< BlockType > &	blockmat_pl
	)

inherited

add the matrix matrix_pl times the constant alpha to this

Parameters

alpha	the constant to multiply the matrix_pl with
blockmat_pl	the BlockStructure to be multiplied by alpha and added to this

Definition at line 172 of file BlockStructure.cpp.

template<class BlockType >

double BlockStructure::ddot ( const BlockStructure< BlockType > & blocks_in ) const

inherited

Returns: inproduct of (*this) blocks with blocks_in, defined as Tr (A B)

Parameters

blocks_in input matrix

Definition at line 293 of file BlockStructure.cpp.

template<class BlockType >

void BlockStructure::dscal ( double alpha )

inherited

Scale the blocks (*this) with parameter alpha

Parameters

alpha scalefactor

Definition at line 320 of file BlockStructure.cpp.

template<class BlockType >

void BlockStructure::fill_Random ( )

inherited

Fill the matrix with random numbers.

Definition at line 331 of file BlockStructure.cpp.

template<class BlockType >

void BlockStructure::fill_Random ( int seed )

inherited

Fill the matrix with random numbers.

Parameters

seed	the seed to use

Definition at line 342 of file BlockStructure.cpp.

void PHM::G ( const TPM & tpm )

Create the G condition from a TPM

Parameters

tpm	the TPM to use

Definition at line 230 of file PHM.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

Matrix PHM::Gbuild ( ) const

Build the full G matrix out of *this object

Returns: the full dense G matrix

Definition at line 296 of file PHM.cpp.

template<class BlockType >

int BlockStructure::gdeg ( int i ) const

inherited

Returns: the degeneracy of the block with index i

Definition at line 268 of file BlockStructure.cpp.

Here is the caller graph for this function:

template<class BlockType >

int BlockStructure::gdim ( int i ) const

inherited

Returns: the dimension of the Matrix on the block with index i

Definition at line 259 of file BlockStructure.cpp.

Here is the caller graph for this function:

const Matrix & PHM::getBlock	(	int	a,
		int	b
	)		const

Get a 2x2 block of the G matrix, corresponding with indices a and b

Parameters

a	the first sp index
b	the second sp index

Returns: the 2x2 matrix

Definition at line 203 of file PHM.cpp.

Here is the caller graph for this function:

Matrix & PHM::getBlock	(	int	a,
		int	b
	)

Get a 2x2 block of the G matrix, corresponding with indices a and b

Parameters

a	the first sp index
b	the second sp index

Returns: the 2x2 matrix

Definition at line 218 of file PHM.cpp.

Matrix PHM::Gimg ( const TPM & tpm ) const

Build the G matrix using the full G matrix image

Parameters

tpm	the TPM to use

Returns: the full G matrix

Definition at line 262 of file PHM.cpp.

int PHM::gL ( ) const

Definition at line 191 of file PHM.cpp.

int PHM::gN ( ) const

Definition at line 186 of file PHM.cpp.

template<class BlockType >

int BlockStructure::gnr ( ) const

inherited

Returns: the blocks.size() of blocks

Definition at line 250 of file BlockStructure.cpp.

Here is the caller graph for this function:

void PHM::invert ( )

virtual

Invert positive semidefinite symmetric blocks which is stored in (*this), original matrix (*this) is destroyed

Reimplemented from doci2DM::BlockStructure< BlockType >.

Definition at line 366 of file PHM.cpp.

Here is the call graph for this function:

void PHM::L_map	(	const BlockMatrix &	map,
		const BlockMatrix &	object
	)

Definition at line 375 of file PHM.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

template<class BlockType >

void BlockStructure::L_map	(	const BlockStructure< BlockType > &	map,
		const BlockStructure< BlockType > &	object
	)

virtualinherited

Multiply symmetric blocks object left en right with symmetric blocks map to form another symmetric blocks and put it in (*this): this = map*object*map

Parameters

map	BlockStructure that will be multiplied to the left en to the right of matrix object
object	central BlockStructure

Definition at line 367 of file BlockStructure.cpp.

template<class BlockType>

double doci2DM::BlockStructure< BlockType >::max ( ) const

inherited

template<class BlockType>

double doci2DM::BlockStructure< BlockType >::min ( ) const

inherited

template<class BlockType >

BlockStructure< BlockType > & BlockStructure::mprod	(	const BlockStructure< BlockType > &	A,
		const BlockStructure< BlockType > &	B
	)

virtualinherited

BlockStructure product of two general blockmatrices A en B, put result in this

Parameters

A	left matrix
B	right matrix

Definition at line 380 of file BlockStructure.cpp.

double PHM::operator()	(	int	a,
		int	b,
		int	c,
		int	d
	)		const

The access operator for the G matrix. It's a bit complicated due to the fact that we don't store the full blown G matrix. We construct each element on the fly

Parameters

a	the first sp index
b	the second sp index
c	the thirth sp index
d	the fourth sp index

Returns: the G matrix element

Definition at line 129 of file PHM.cpp.

template<class BlockType>

double& doci2DM::BlockStructure< BlockType >::operator()	(	int	block,
		int	i,
		int	j
	)

inherited

template<class BlockType>

double doci2DM::BlockStructure< BlockType >::operator()	(	int	block,
		int	i,
		int	j
	)		const

inherited

template<class BlockType>

double& doci2DM::BlockStructure< BlockType >::operator()	(	int	block,
		int	index
	)

inherited

template<class BlockType>

double doci2DM::BlockStructure< BlockType >::operator()	(	int	block,
		int	index
	)		const

inherited

template<class BlockType >

BlockStructure< BlockType > & BlockStructure::operator*= ( double c )

inherited

Definition at line 196 of file BlockStructure.cpp.

template<class BlockType >

BlockStructure< BlockType > & BlockStructure::operator+= ( const BlockStructure< BlockType > & blockmat_pl )

inherited

overload the += operator for matrices

Parameters

blockmat_pl The matrix you want to add to this

Definition at line 143 of file BlockStructure.cpp.

template<class BlockType >

BlockStructure< BlockType > & BlockStructure::operator-= ( const BlockStructure< BlockType > & blockmat_pl )

inherited

overload the -= operator for matrices

Parameters

blockmat_pl The matrix you want to deduct from this

Definition at line 157 of file BlockStructure.cpp.

template<class BlockType >

BlockStructure< BlockType > & BlockStructure::operator/= ( double c )

inherited

/= operator overloaded: divide by a constant

Parameters

c	the number to divide your matrix through

Definition at line 186 of file BlockStructure.cpp.

PHM& doci2DM::PHM::operator= ( const PHM & )

default

PHM& doci2DM::PHM::operator= ( PHM && )

default

template<class BlockType >

BlockType & BlockStructure::operator[] ( int block )

inherited

[] overloaded, will return a reference to the block block in the blocks.

Parameters

block index of the block to be returned

Returns: A reference to the Matrix object located on blocks[block].

Definition at line 91 of file BlockStructure.cpp.

template<class BlockType >

const BlockType & BlockStructure::operator[] ( int block ) const

inherited

[] overloaded, const version, will return a const reference to the block block in the blocks.

Parameters

block index of the block to be returned

Returns: A reference to the Matrix object located on blocks[block].

Definition at line 102 of file BlockStructure.cpp.

void PHM::ReadFromFile ( hid_t & group_id )

Read a PHM object from a HDF5 group. The PHM object must already exist and have the correct dimensions. It will fill the object called on

Parameters

group_id reference to the HDF5 group to use

Definition at line 499 of file PHM.cpp.

Here is the call graph for this function:

void PHM::sep_pm	(	BlockMatrix &	pos,
		BlockMatrix &	neg
	)

Use the 2x2 sep_pm for all the 2x2 blocks instead of the full blown sep_pm

Parameters

pos	the positive part of the matrix
neg	the negative part of the matrix

Definition at line 343 of file PHM.cpp.

Here is the call graph for this function:

template<class BlockType >

void BlockStructure::sep_pm	(	BlockStructure< BlockType > &	pos,
		BlockStructure< BlockType > &	neg
	)

virtualinherited

Definition at line 410 of file BlockStructure.cpp.

template<class BlockType >

void BlockStructure::setDim	(	int	block,
		int	dim,
		int	degeneracy
	)

inherited

function that allocates the memory of the blocks block with dimension dim sets and the degeneracy of the matrix

Parameters

block	the index of the block that will be allocated
dim	the dimension of the particular block to be allocated
degeneracy	the degeneracy of block "block"

Definition at line 76 of file BlockStructure.cpp.

Here is the caller graph for this function:

template<class BlockType>

void doci2DM::BlockStructure< BlockType >::sort ( )

inherited

template<>

void doci2DM::BlockStructure< Vector >::sort ( )

inherited

Definition at line 402 of file BlockStructure.cpp.

void PHM::sqrt ( int option )

virtual

Pull the sqrt out of this matrix. Optimized for the structure of the 2x2 matrices

Parameters

option 1 => positive sqrt, -1 => negative sqrt

Reimplemented from doci2DM::BlockStructure< BlockType >.

Definition at line 357 of file PHM.cpp.

Here is the call graph for this function:

template<class BlockType >

void BlockStructure::symmetrize ( )

inherited

Copy upper triangle into lower triangle.

Definition at line 393 of file BlockStructure.cpp.

template<class BlockType >

double BlockStructure::trace ( ) const

inherited

Returns: the trace of the matrix, each block matrix is weighed with its degeneracy.

Definition at line 277 of file BlockStructure.cpp.

Here is the caller graph for this function:

void PHM::WriteFullToFile ( hid_t & group_id ) const

Definition at line 435 of file PHM.cpp.

Here is the call graph for this function:

void PHM::WriteToFile ( hid_t & group_id ) const

Write a PHM object to a HDF5 group

Parameters

group_id reference to the HDF5 group to use

Definition at line 388 of file PHM.cpp.

Here is the call graph for this function:

Friends And Related Function Documentation

std::ostream& operator<<	(	std::ostream &	output,
		doci2DM::PHM &	phm
	)

friend

Definition at line 320 of file PHM.cpp.

Member Data Documentation

std::unique_ptr< helpers::tmatrix< int > > PHM::b2s = nullptr

staticprivate

table translating the block index to the single particle indices

Definition at line 108 of file PHM.h.

int doci2DM::PHM::L

private

Definition at line 94 of file PHM.h.

int doci2DM::PHM::N

private

Definition at line 96 of file PHM.h.

std::unique_ptr< helpers::tmatrix< int > > PHM::ph2s = nullptr

staticprivate

table translating two particles indices to single particle indices

Definition at line 102 of file PHM.h.

std::unique_ptr< helpers::tmatrix< int > > PHM::s2b = nullptr

staticprivate

table translating single particles indices to the correct 2x2 block

Definition at line 105 of file PHM.h.

std::unique_ptr< helpers::tmatrix< int > > PHM::s2ph = nullptr

staticprivate

table translating single particles indices to two particle indices

Definition at line 99 of file PHM.h.

The documentation for this class was generated from the following files:

include/PHM.h
PHM.cpp

Public Member Functions

Private Member Functions

Private Attributes

Static Private Attributes

Friends

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
