#include <OrbitalTransform.h>

Collaboration diagram for simanneal::OrbitalTransform:

Public Member Functions
	OrbitalTransform (const CheMPS2::Hamiltonian &ham)

virtual	~OrbitalTransform ()=default

void	fillHamCI (CheMPS2::Hamiltonian &HamCI)

void	fillConstAndTmat (CheMPS2::Hamiltonian &Ham) const

void	buildOneBodyMatrixElements ()

void	set_unitary (UnitaryMatrix &unit)

CheMPS2::Hamiltonian &	get_ham ()

const CheMPS2::Hamiltonian &	get_ham () const

double	TmatRotated (const int index1, const int index2) const

double	get_norb (int irrep) const

double	get_difference_orig (CheMPS2::Hamiltonian &hamin) const

void	CheckDeviationFromUnitary () const

void	update_unitary (double *step)

UnitaryMatrix &	get_unitary ()

UnitaryMatrix &	get_unitary () const

void	DoJacobiRotation (CheMPS2::Hamiltonian &, int k, int l, double theta)

void	update_unitary (const UnitaryMatrix &, bool replace=false)

Private Member Functions
void	rotate_old_to_new (std::unique_ptr< double[]> *matrix)

Private Attributes
std::unique_ptr< CheMPS2::Hamiltonian >	_hamorig
	the orginal hamiltonian More...

std::unique_ptr< simanneal::UnitaryMatrix >	_unitary
	The rotation to perfrom on _hamorig to get the current hamiltonian. More...

std::unique_ptr< CheMPS2::Hamiltonian >	ham_rot

OptIndex	index

CheMPS2::Irreps	SymmInfo

int	numberOfIrreps

std::vector< std::unique_ptr< double[]> >	QmatrixWork
	Some memory to do the one body work, allocated when needed. More...

std::vector< std::unique_ptr< double[]> >	OneBodyMatrixElements

std::unique_ptr< double[]>	mem1

std::unique_ptr< double[]>	mem2

Detailed Description

Definition at line 16 of file OrbitalTransform.h.

Constructor & Destructor Documentation

OrbitalTransform::OrbitalTransform ( const CheMPS2::Hamiltonian & ham )

Definition at line 35 of file OrbitalTransform.cpp.

Here is the call graph for this function:

virtual simanneal::OrbitalTransform::~OrbitalTransform ( )

virtualdefault

Member Function Documentation

void OrbitalTransform::buildOneBodyMatrixElements ( )

This method fills the OneBodyMatrixElements array with the 1-body matrix elements so we can rotate them

Definition at line 138 of file OrbitalTransform.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void OrbitalTransform::CheckDeviationFromUnitary ( ) const

Definition at line 247 of file OrbitalTransform.cpp.

void OrbitalTransform::DoJacobiRotation	(	CheMPS2::Hamiltonian &	ham_rot,
		int	k,
		int	l,
		double	theta
	)

Update ham_rot in place with a jacobi rotation between orbital k and l over an angle of theta. k and l should be in the same irrep.

Parameters

ham_rot	The Hamiltonian to update
k	the first orbital
l	the second orbital
theta	the angle to rotation over

Returns: an rotated Hamiltonian

Definition at line 288 of file OrbitalTransform.cpp.

Here is the call graph for this function:

void OrbitalTransform::fillConstAndTmat ( CheMPS2::Hamiltonian & Ham ) const

Definition at line 221 of file OrbitalTransform.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void OrbitalTransform::fillHamCI ( CheMPS2::Hamiltonian & HamCI )

Definition at line 64 of file OrbitalTransform.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

double OrbitalTransform::get_difference_orig ( CheMPS2::Hamiltonian & hamin ) const

Definition at line 240 of file OrbitalTransform.cpp.

CheMPS2::Hamiltonian& simanneal::OrbitalTransform::get_ham ( )

inline

Definition at line 26 of file OrbitalTransform.h.

const CheMPS2::Hamiltonian& simanneal::OrbitalTransform::get_ham ( ) const

inline

Definition at line 27 of file OrbitalTransform.h.

double OrbitalTransform::get_norb ( int irrep ) const

Definition at line 257 of file OrbitalTransform.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

UnitaryMatrix& simanneal::OrbitalTransform::get_unitary ( )

inline

Definition at line 35 of file OrbitalTransform.h.

Here is the caller graph for this function:

UnitaryMatrix& simanneal::OrbitalTransform::get_unitary ( ) const

inline

Definition at line 36 of file OrbitalTransform.h.

void OrbitalTransform::rotate_old_to_new ( std::unique_ptr< double[]> * matrix )

private

Calculates the rotation of the 1-body matrix T' = Q * T * Q^T It uses the OneBodyMatrixElements array as start and endpoint point and uses the Qmatrixwork as temp storage

Definition at line 180 of file OrbitalTransform.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void OrbitalTransform::set_unitary ( UnitaryMatrix & unit )

Definition at line 252 of file OrbitalTransform.cpp.

double OrbitalTransform::TmatRotated	(	const int	index1,
		const int	index2
	)		const

Definition at line 201 of file OrbitalTransform.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void OrbitalTransform::update_unitary ( double * step )

Definition at line 262 of file OrbitalTransform.cpp.

Here is the caller graph for this function:

void OrbitalTransform::update_unitary	(	const UnitaryMatrix &	X,
		bool	replace = `false`
	)

Update the unitary matrix with exp(X). In X you should store an anti-symmetric real matrix.

Parameters

X	the anti-symmetric real matrix
replace	replace or multiply? By default do exp(X)*U

Definition at line 273 of file OrbitalTransform.cpp.

Member Data Documentation

std::unique_ptr<CheMPS2::Hamiltonian> simanneal::OrbitalTransform::_hamorig

private

the orginal hamiltonian

Definition at line 46 of file OrbitalTransform.h.

std::unique_ptr<simanneal::UnitaryMatrix> simanneal::OrbitalTransform::_unitary

private

The rotation to perfrom on _hamorig to get the current hamiltonian.

Definition at line 48 of file OrbitalTransform.h.

std::unique_ptr<CheMPS2::Hamiltonian> simanneal::OrbitalTransform::ham_rot

private

Definition at line 50 of file OrbitalTransform.h.

OptIndex simanneal::OrbitalTransform::index

private

Definition at line 52 of file OrbitalTransform.h.

std::unique_ptr<double []> simanneal::OrbitalTransform::mem1

private

Definition at line 61 of file OrbitalTransform.h.

std::unique_ptr<double []> simanneal::OrbitalTransform::mem2

private

Definition at line 62 of file OrbitalTransform.h.

int simanneal::OrbitalTransform::numberOfIrreps

private

Definition at line 54 of file OrbitalTransform.h.

std::vector< std::unique_ptr<double []> > simanneal::OrbitalTransform::OneBodyMatrixElements

private

Definition at line 59 of file OrbitalTransform.h.

std::vector< std::unique_ptr<double []> > simanneal::OrbitalTransform::QmatrixWork

private

Some memory to do the one body work, allocated when needed.

Definition at line 57 of file OrbitalTransform.h.

CheMPS2::Irreps simanneal::OrbitalTransform::SymmInfo

private

Definition at line 53 of file OrbitalTransform.h.

The documentation for this class was generated from the following files:

extern/include/OrbitalTransform.h
extern/OrbitalTransform.cpp
