helpers::SparseMatrix_CRS Class Reference

#include <SparseMatrix_CRS.h>

Public Member Functions
	SparseMatrix_CRS (unsigned int n)
virtual	~SparseMatrix_CRS ()=default
double	operator() (unsigned int i, unsigned int j) const
unsigned int	gn () const
void	ConvertFromMatrix (const helpers::matrix &dense)
void	ConvertToMatrix (helpers::matrix &dense) const
void	PrintRaw () const
void	PushToRow (unsigned int j, double value)
void	PushToRowNext (unsigned int j, double value)
void	NewRow ()
void	mvprod (const double *, double *) const
void	mvprod (const double *, double *, double) const
void	SetGuess (unsigned int)
int	WriteToFile (const char *, const char *, bool=false) const
int	ReadFromFile (const char *, const char *)
unsigned int	NumOfElInRow (unsigned int idx) const
double	GetElementInRow (unsigned int row_index, unsigned int element_index) const
unsigned int	GetElementColIndexInRow (unsigned int row_index, unsigned int element_index) const
void	AddList (std::vector< std::unique_ptr< SparseMatrix_CRS > > &)
	SparseMatrix_CRS (unsigned int n)
virtual	~SparseMatrix_CRS ()=default
double	operator() (unsigned int i, unsigned int j) const
unsigned int	gn () const
void	ConvertFromMatrix (const helpers::matrix &dense)
void	ConvertToMatrix (helpers::matrix &dense) const
void	PrintRaw () const
void	PushToRow (unsigned int j, double value)
void	PushToRowNext (unsigned int j, double value)
void	NewRow ()
void	mvprod (const double *, double *) const
void	mvprod (const double *, double *, double) const
void	SetGuess (unsigned int)
int	WriteToFile (const char *, const char *, bool=false) const
int	ReadFromFile (const char *, const char *)
unsigned int	NumOfElInRow (unsigned int idx) const
double	GetElementInRow (unsigned int row_index, unsigned int element_index) const
unsigned int	GetElementColIndexInRow (unsigned int row_index, unsigned int element_index) const
void	AddList (std::vector< std::unique_ptr< SparseMatrix_CRS > > &)

Friends
std::ostream &	operator<< (std::ostream &output, helpers::SparseMatrix_CRS &matrix_p)
std::ostream &	operator<< (std::ostream &output, helpers::SparseMatrix_CRS &matrix_p)

Detailed Description

Author

Ward Poelmans

Date

03-07-2012

This is a class written for sparse n x n matrices to use on the gpu. It uses the CRS format to store a matrix. Only symmetric matrices!

Definition at line 22 of file SparseMatrix_CRS.h.

Constructor & Destructor Documentation

SparseMatrix_CRS::SparseMatrix_CRS

(

unsigned int

n

)

Construct SparseMatrix_CRS object for n x n matrix

Parameters

n	the number of rows/columns

Definition at line 18 of file SparseMatrix_CRS.cpp.

virtual helpers::SparseMatrix_CRS::~SparseMatrix_CRS ( )

virtualdefault

helpers::SparseMatrix_CRS::SparseMatrix_CRS

(

unsigned int

n

)

virtual helpers::SparseMatrix_CRS::~SparseMatrix_CRS ( )

virtualdefault

Member Function Documentation

void SparseMatrix_CRS::AddList

(

std::vector< std::unique_ptr< SparseMatrix_CRS > > &

list

)

Add a bunch of non-overlapping, in order, Sparse Matrices together to the current object (overwriting any previous data). This is used if threads each builded a part of the matrix into seperate SparseMatrix_CRS objects. After the parallel part, this method builds the final Sparse Matrix. We also assume that the matrices in the list are in order: the first rows first, etc This method is tuned for the DOCIHamiltonian::Build_iter(), it's not general!

Warning

this means you will have 2 copies of the entire Sparse Matrix in memory during this method.

Parameters

list	the list of pointer to the Sparse Matrices

Definition at line 524 of file SparseMatrix_CRS.cpp.

void helpers::SparseMatrix_CRS::AddList

(

std::vector< std::unique_ptr< SparseMatrix_CRS > > &

)

void SparseMatrix_CRS::ConvertFromMatrix

(

const helpers::matrix &

dense

)

Convert a dense matrix to CRS format

Parameters

dense

the matrix to convert

Definition at line 53 of file SparseMatrix_CRS.cpp.

Here is the call graph for this function:

void helpers::SparseMatrix_CRS::ConvertFromMatrix

(

const helpers::matrix &

dense

)

void SparseMatrix_CRS::ConvertToMatrix

(

helpers::matrix &

dense

)

const

Convert this CRS matrix to a dense symmetric matrix (only works for square matrices)

Parameters

dense

the matrix to fill

Definition at line 83 of file SparseMatrix_CRS.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void helpers::SparseMatrix_CRS::ConvertToMatrix

(

helpers::matrix &

dense

)

const

unsigned int helpers::SparseMatrix_CRS::GetElementColIndexInRow	(	unsigned int	row_index,
		unsigned int	element_index
	)		const

unsigned int SparseMatrix_CRS::GetElementColIndexInRow	(	unsigned int	row_index,
		unsigned int	element_index
	)		const

Get the column number of a element in a row. Used together with GetElementInRow()

Parameters

row_index	the index of the row
element_index	the index of the element in the row (index of the non-zero elements, not the column index)

Returns

the column number of the element

Definition at line 496 of file SparseMatrix_CRS.cpp.

double helpers::SparseMatrix_CRS::GetElementInRow	(	unsigned int	row_index,
		unsigned int	element_index
	)		const

double SparseMatrix_CRS::GetElementInRow	(	unsigned int	row_index,
		unsigned int	element_index
	)		const

Get a element out of a row

Parameters

row_index	the number of the row where to get an element of
element_index	the index of the element (index of the non-zero elements, not the column index)

Returns

the value of the element

Definition at line 485 of file SparseMatrix_CRS.cpp.

unsigned int helpers::SparseMatrix_CRS::gn

(

)

const

unsigned int SparseMatrix_CRS::gn

(

)

const

Returns

the number of rows

Definition at line 44 of file SparseMatrix_CRS.cpp.

Here is the caller graph for this function:

void SparseMatrix_CRS::mvprod	(	const double *	x,
		double *	y
	)		const

Do the matrix vector product y = A * x

Parameters

x	a m component vector
y	a n component vector

Definition at line 219 of file SparseMatrix_CRS.cpp.

Here is the caller graph for this function:

void helpers::SparseMatrix_CRS::mvprod	(	const double *	,
		double *
	)		const

void SparseMatrix_CRS::mvprod	(	const double *	x,
		double *	y,
		double	beta
	)		const

Do the matrix vector product y = A * x + beta * y

Parameters

x	a m component vector
y	a n component vector
beta	the multiply factor for y

Definition at line 258 of file SparseMatrix_CRS.cpp.

void helpers::SparseMatrix_CRS::mvprod	(	const double *	,
		double *	,
		double
	)		const

void helpers::SparseMatrix_CRS::NewRow

(

)

void SparseMatrix_CRS::NewRow

(

)

Adds the next row to the sparsematrix

Definition at line 193 of file SparseMatrix_CRS.cpp.

unsigned int helpers::SparseMatrix_CRS::NumOfElInRow

(

unsigned int

idx

)

const

unsigned int SparseMatrix_CRS::NumOfElInRow

(

unsigned int

idx

)

const

Get the number of elements in a row

Parameters

idx	the row to consider

Returns

the number of non-zero elements in row idx

Definition at line 474 of file SparseMatrix_CRS.cpp.

double SparseMatrix_CRS::operator()	(	unsigned int	i,
		unsigned int	j
	)		const

Read only access operator

Parameters

i	the row number
j	the column number

Returns

the matrix element

Definition at line 30 of file SparseMatrix_CRS.cpp.

double helpers::SparseMatrix_CRS::operator()	(	unsigned int	i,
		unsigned int	j
	)		const

void SparseMatrix_CRS::PrintRaw

(

)

const

Print the raw CRS data to stdout

Definition at line 96 of file SparseMatrix_CRS.cpp.

void helpers::SparseMatrix_CRS::PrintRaw

(

)

const

void SparseMatrix_CRS::PushToRow	(	unsigned int	j,
		double	value
	)

Adds a new column element to the current row. To use this, first call NewRow() to start a row and then use PushToRow() to add elements to that row. Always end with calling NewRow() again.

Parameters

j	column
value	the matrix element value

Definition at line 137 of file SparseMatrix_CRS.cpp.

void helpers::SparseMatrix_CRS::PushToRow	(	unsigned int	j,
		double	value
	)

void helpers::SparseMatrix_CRS::PushToRowNext	(	unsigned int	j,
		double	value
	)

void SparseMatrix_CRS::PushToRowNext	(	unsigned int	j,
		double	value
	)

Adds a new column element to the current row. To use this, first call NewRow() to start a row and then use PushToRowNext() to add elements to that row. Always end with calling NewRow() again.

IMPORTANT: the PushToRow is a general function, you can push values to the row in any order. This method assumes you always add a new element in a column next to the previous one.

Parameters

j	column
value	the matrix element value

Definition at line 182 of file SparseMatrix_CRS.cpp.

int helpers::SparseMatrix_CRS::ReadFromFile	(	const char *	,
		const char *
	)

int SparseMatrix_CRS::ReadFromFile	(	const char *	filename,
		const char *	name
	)

Read a SparseMatrix_CRS from a HDF5 file

Parameters

filename	the name of the file to read from
name	the name of the group in the HDF5 file

Definition at line 384 of file SparseMatrix_CRS.cpp.

Here is the caller graph for this function:

void SparseMatrix_CRS::SetGuess

(

unsigned int

count

)

Set a guess for the number of non-zero elements in the matrix. This method will reserve enough memory to store at least count elements

Parameters

count

the number of guessed non-zero elements

Definition at line 508 of file SparseMatrix_CRS.cpp.

void helpers::SparseMatrix_CRS::SetGuess

(

unsigned

int

)

int SparseMatrix_CRS::WriteToFile	(	const char *	filename,
		const char *	name,
		bool	append = false
	)		const

Save a SparseMatrix_CRS to a HDF5 file

Parameters

filename	the name of the file to write to
name	the name of the group in the HDF5 file
append	add or overwrite file

Definition at line 290 of file SparseMatrix_CRS.cpp.

Here is the caller graph for this function:

int helpers::SparseMatrix_CRS::WriteToFile	(	const char *	,
		const char *	,
		bool	= false
	)		const

Friends And Related Function Documentation

std::ostream& operator<< ( std::ostream &  output, helpers::SparseMatrix_CRS &  matrix_p  )

friend

Output stream operator overloaded, the usage is simple, if you want to print to a file, make an ifstream object and type:

object << matrix << endl;

For output onto the screen type:

cout << matrix << endl;

Parameters

output	The stream to which you are writing (e.g. cout)
matrix_p	de SparseMatrix_CRS you want to print

Print sparse matrix to output

Parameters

output	the ostream to print to
matrix_p	the matrix to print

Returns

the filled ostream (with the matrix)

Definition at line 120 of file SparseMatrix_CRS.cpp.

std::ostream& operator<< ( std::ostream &  output, helpers::SparseMatrix_CRS &  matrix_p  )

friend

Output stream operator overloaded, the usage is simple, if you want to print to a file, make an ifstream object and type:

object << matrix << endl;

For output onto the screen type:

cout << matrix << endl;

Parameters

output	The stream to which you are writing (e.g. cout)
matrix_p	de SparseMatrix_CRS you want to print

Print sparse matrix to output

Parameters

output	the ostream to print to
matrix_p	the matrix to print

Returns

the filled ostream (with the matrix)

Output stream operator overloaded, the usage is simple, if you want to print to a file, make an ifstream object and type:

object << matrix << endl;

For output onto the screen type:

cout << matrix << endl;

Parameters

output	The stream to which you are writing (e.g. cout)
matrix_p	de SparseMatrix_CRS you want to print

Print sparse matrix to output

Parameters

output	the ostream to print to
matrix_p	the matrix to print

Returns

the filled ostream (with the matrix)

Definition at line 120 of file SparseMatrix_CRS.cpp.

---

The documentation for this class was generated from the following files:

• DOCI-Exact/include/SparseMatrix_CRS.h
• DOCI-Exact/SparseMatrix_CRS.cpp
